振动、冲击环境下支架减振器刚度优化设计

王东升, 周 桐, 李 健

王东升, 周 桐, 李 健. 振动、冲击环境下支架减振器刚度优化设计[J]. 航天器环境工程, 2006, 23(2): 86-89
引用本文: 王东升, 周 桐, 李 健. 振动、冲击环境下支架减振器刚度优化设计[J]. 航天器环境工程, 2006, 23(2): 86-89
WANG Dongsheng, ZHOU Tong, LI Jian. Optimal Design of Bracket Isolator Stiffness in Vibration and Shock Environment[J]. Spacecraft Environment Engineering, 2006, 23(2): 86-89.
Citation: WANG Dongsheng, ZHOU Tong, LI Jian. Optimal Design of Bracket Isolator Stiffness in Vibration and Shock Environment[J]. Spacecraft Environment Engineering, 2006, 23(2): 86-89.

振动、冲击环境下支架减振器刚度优化设计

基金项目:

中国工程物理研究院总体工程研究所创新与发展基金资助课题(06CXJ-32)

Optimal Design of Bracket Isolator Stiffness in Vibration and Shock Environment

  • 摘要: 文章在某型号的电子设备支架减振器设计中,综合考虑了振动、冲击两种主要的力学环境。以减振器刚度为设计变量,将刚度的倒数作为目标函数,根据振动、冲击环境设计要求确定了约束条件,建立了减振器刚度优化的数学模型。采用ANSYS作为优化设计的平台,随机振动响应分析采用振型叠加法,冲击响应分析采用Newmark时间积分法,对该问题进行了优化求解,取得了满意的结果,为电子学系统的减振设计提供了依据。
    Abstract: In this paper, the bracket of a electric equipment is designed by considering the vibration and shock environment. According to the design requirement with respect to vibration and shock, the stiffness of the isolator is used as the design variable. The mathematical optimal model for searching the largest stiffness of isolator is built to make the relative displacement small. The optimal problem is solved using ANSYS. Both the mode superposition method and the Newmark integrating method are used to obtain the response of stochastic vibration and shock. The optimal results could be used in the isolator design of the electric system.
  • [1] 徐燕申, 等. 机械动态设计[M].北京:机械工业出版社, 1992 [Xu Yanshen,et al. Dynamic design of mechanical systems[M]. Beijing: Mechanical Industry Press, 1992] [2] 徐庆善.隔振技术的进展与动态[J].机械强度,1994,16(1):37~42 [Xue Qingshan. The advance and trends of vibration isolated technique[J].Journal of Mechanical Strength, 1994,16(1):37~42] [3] 陈翀, 吴自恒. 非线性钢丝绳隔振器特性及其应用[J].四川工业学院学报,1999,18(1):1~7 [Chen Chong, Wu Ziheng. Characteristics and application of nonlinear wire-rope vibration isolator[J]. Journal of Sichuan University of Science and Technology, 1999, 18(1):1~7] [4] 生建友. 机载电子设备的防振动抗冲击设计[J].电子机械工程, 1999, 2:44~47 [Sheng Jianyou. Guarding against vibration and resisting lash design of airborne electronic equipment[J]. Electronics Machinery Engineering, 1999,2:44~47] [5] 廖道训,黄孝成,陆永忠.多层隔振系统的动力学方程[J].中国机械工程, 1999, 10(12):1321~1324[Liao Daoxun, Huang Xiaocheng, Lu Yongzhong. Theory and method of dynamic modeling for multilayer vibration isolation system[J]. China Mechanical Engineering, 1999,10(12):1321~1324] [6] 翁雪涛, 等. 减振系统的抗冲击性能计算[J]. 噪声与振动控制, 1999, 2:16~18[Weng Xuetao, et al. Computation about the shock resistance performance of vibration reduction system[J]. Noise and Vibration Control, 1999, 2:16~18] [7] 温建明, 等. 减振元件冲击特性研究[J].噪声与振动控制, 2001, 2:18~21 [Wen Jianming, et al. Study on impact characteristic about buffer component[J]. Noise and Vibration Control,2001,2:18~21] [8] 毛南敏.冲击隔振器设计的一种新方法[J].噪声与振动控制, 1997, 1:22~25 [Mao Nanmin. A new design methed of shock isolators[J]. Noise and Vibration Control, 1997, 1:22~25] [9] 刘勇, 等. 非线性振冲隔离系统的仿真研究[J].机械科学与技术, 1999, 18(2):204~206 [Liu Yong, et al. Research on simulation of vibration and shock isolation for nonlinear system[J]. .Mechancal Science and Technology, 1999, 18(2):204~206] [10] 战嘉恺,等. 振动和冲击隔离中阻尼作用与取值范围分析[J]. 噪声与振动控制,1998,3:21~25 [Zhan Jiakai, et al. Effect and range of damping on the reduction of vibration and shock[J]. Noise and Vibration Control, 1998,3:21~25] [11] 陈继红. 振动隔离与冲击隔离的区别[J]. 噪声与振动控制, 1996, 1:31~33 [Chen Jihong. The difference of isolation between vibration and shock[J]. Noise and Vibration Control, 1996, 1:31~33]
