Thermal design of SADA and its detailed temperature distribution in HT condition for geostationary orbit satellite
-
摘要: 针对地球静止轨道卫星SADA轴系周向或轴向温度梯度过大导致卡死的故障情况，开展某卫星SADA热设计、热仿真及太阳模拟器光照试验研究。采用挡光板及均温措施等热设计减小SADA温度梯度及外热流影响。试验外热流模拟冬至工况，舱内边界温度25℃，通过在其内部和外部布置88个温度测点，得出SADA内部的电缆束、功率盘片及电刷温度较高。轴系两端面周向最大温差分别为1.2℃和8℃，轴系两端面最大温差6.8℃。在此温度环境下，SADA工作正常，证明了其本身及热控设计的合理性。热仿真计算结果与试验结果一致性较好。研究结果还得到了在轨数据的验证。SADA数学模型、试验方法和结果可为后续型号不同工况条件工作的SADA提供热设计指导。Abstract: The large temperature gradient in the circumferential and axial directions of the bearing can lead to a seizure failure. The thermal design, the thermal simulation and the thermal vacuum experiment based on solar simulator are carried out, and the detailed temperature distribution of the SADA is obtained. The light barrier and the temperature uniformity measures are taken to reduce the temperature gradient and the influence of the external heat flux. In the thermal experiment, the external heat flux is the same as that in the winter solstice. The boundary temperature of the cabin plates is 25℃. Eighty-eight thermal couples are installed to collect the temperature data for the SADA. The bunch of cables, the slip ring assembly and the electrical brushes are the locations with higher temperature. The maximum temperature differences are 1.2℃ and 8℃ on the head face and the end face of the bearing in the circumferencial direction. The maximum temperature difference is 6.8℃ between the head face and the end face of the bearing in the axial direction. The SADA can work well under these temperature conditions. It is shown that the SADA design and the thermal control design are reasonable. The results of the thermal simulation are consistent with the experiment results. The results are also verified by the on-orbit data. The thermal analysis model, the experimental methods and the test results can be used in the subsequent thermal designs and the temperature distribution researches of the SADA under different working conditions.
-
-
[1] AUER W. A family of BAPTAs for GEO and LEO applications:19890014537[R]. Washington:NASA, 1989:241-253
[2] 马兴瑞, 于登云, 孙京, 等. 空间飞行器展开与驱动机构研究进展[J]. 宇航学报, 2006, 27(6):1123-1131 MA X R, YU D Y, SUN J, et al. The researching evolvement of spacecraft deployment and driving mechanism[J]. Journal of Astronautics, 2006, 27(6):1123-1131 [3] 梁斌, 徐文福, 李成, 等. 地球静止轨道在轨服务技术研究现状与发展趋势[J]. 宇航学报, 2010, 31(1):1-13 LIANG B, XU W F, LI C, et al. The status and prospect of orbital servicing in the geostationary orbit[J]. Journal of Astronautics, 2010, 31(1):1-13 [4] SULLIVAN B R, AKIN D L. A survey of serviceable spacecraft failures[C]//AIAA Space Conference and Exposition. Albuquerque, NM, 2001:AIAA 2001-4540
[5] TAFAZOLI M. A study of on-orbit spacecraft failures[J]. Acta Astronautica, 2009, 64:195-205
[6] 吴亚光, 马利. 地球同步轨道卫星SADA在轨温度趋势分析[C]//第二届中国卫星导航学术年会. 上海, 2011:1-4 [7] 李进, 卢威. 基于IDEAS的大功率SADA热分析仿真与实验研究[C]//国防科技会议. 北京, 2012:378-389 [8] 易桦, 赵啟伟, 周晓云. 高热耗太阳帆板驱动机构热设计[C]//第十二届空间热物理会议. 兰州, 2015:104-110 [9] 李超. 星载盘式滑环电刷材料的选择和试验[J]. 电子机械工程, 2009, 25(3):6-9 LI C. Choice of material and experiment on spaceborne disk slip-ring brush[J]. Electro-Mechanical Engineering, 2009, 25(3):6-9 [10] 李超. 星载盘式滑环设计[C]//中国电子学会2009年机械电子学学术会议. 太原, 2009:169-172 [11] 黄本诚, 庞贺伟, 臧友竹, 等. KM6太阳模拟器的研制方案与进展[J]. 航天器环境工程, 2003, 20(1):1-4 HUANG B C, PANG H W, ZANG Y Z, et al. The conception and the development of KM6 solar simulator[J]. Spacecraft Environment Engineering, 2003, 20(1):1-4 [12] 杨林华. 大型太阳模拟器研制技术综述[J]. 航天器环境工程, 2012, 29(2):173-178 YANG L H. Large solar simulator development technologies[J]. Spacecraft Environment Engineering, 2012, 29(2):173-178 -
