Non-contact transferred potential measurement technology in ground testing for spacecraft dielectric charging effect simulation
-
摘要: 航天器充放电效应地面模拟试验中需要测量的一个重要参数是介质的充电电位。文章基于介质充电电位的非接触式转接测量技术,分析了测量中引起误差的各个因素,讨论了减小测量误差和提高转接测量分辨率的方法,并进行试验验证。据此设计了一套介质电位非接触式转接测量系统,其测量分辨率达到10 V以下,且由电荷泄漏引起的测量误差< 1%,能够满足航天器介质充电电位的测量要求。Abstract: The dielectric charging potential is one of the important parameters to be measured in the charging and discharging effect simulation test. A non-contact transferred measurement method is presented, the influencing factors on the measurement errors are analyzed, the methods for improving the transferred measurement resolution are proposed, and a non-contact measurement system with a transfer mechanism is designed. The validation test results show that the resolution of the dielectric charging voltage is less than 10 V, and the error caused by the charge leakage is less than 1%. The system can meet the requirements of the spacecraft dielectric charging potential measurement.
-
-
[1] Rodgers D J, Ryden K A. Internal charging in space[R]. European Space Agency, 2011
[2] Leach R D, Alexander M B. Failures and anomalies attributed to spacecraft charging, NASA Reference Publication 1375[R], 1995
[3] Violet M D, Frederickson A R. Spacecraft anomalies on the CRRES satellite correlated with the environment and insulator samples[J]. IEEE Transactions on Nuclear Science, 1993, 40(6):1512-1520
[4] 全荣辉. 航天器介质深层充放电特征及其影响[D]. 北京:中国科学院空间科学与应用研究中心, 2009 [5] 张荣奇, 谭志良, 林永涛, 等. 常用静电测量技术及其特点[J]. 装备环境工程, 2007, 4(5):85-88 Zhang Rongqi, Tan Zhiliang, Lin Yongtao, et al. Overview on electrostatic testing technologies and there characteristics[J]. Equipment Environmental Engineering, 2007, 4(5):85-88 [6] Frederickson A R, Benson C E, Bockman J F. Measurement of charge storage and leakage in polyimides[J]. Nuclear Instruments and Methods in Physics Research B, 2003, 208:454-460
[7] Fredrickson A R, Dennison J R. Measurement of conductivity and charge storage in insulators related to spacecraft charging[J]. IEEE Transactions on Nuclear Science, 2003, 50(6):2284-2290
[8] Hodges J L, Dennison J R, Dekany J, et al. In situ surface voltage measurements of dielectrics under electron beam irradiation[J]. IEEE Transactions on Plasma Science, 2014, 42(1):255-265
[9] 张振龙, 韩建伟, 曹旭纬, 等. 航天器内部充电模拟装置及其应用[J]. 抗核加固, 2013, 30(1):41-47 [10] 魏明, 叶伟, 魏光辉. 非接触式静电电压表校验研究[J]. 仪表技术与传感器, 2002(12):46-48 Wei Ming, Ye Wei, Wei Guanghui. Study on verification of non-contact electrostatic voltmeter[J]. Instrument Technique and Sensor, 2002(12):46-48 [11] 张要强, 郑晓泉, 刘晓东, 等. 真空环境下介质表面电荷分布的测量方法[J]. 绝缘材料, 2006, 39(3):61-63 Zhang Yaoqiang, Zheng Xiaoquan, Liu Xiaodong, et al. Measurement methods of surface charge distribution on dielectric in vacuum environment[J]. Insulating Materials, 2006, 39(3):61-63
